How to Add Axis IP Camera to Hikvision NVR in 2026

Key Takeaways

• Verify compatibility: Check Axis camera and Hikvision NVR support ONVIF or RTSP protocols.
• Assign static IP: Set a fixed IP address for the Axis camera to avoid connection drops.
• Enable ONVIF: Activate ONVIF on the Axis camera for seamless NVR integration.
• Add via Hik-Connect: Use the Hik-Connect app to auto-detect and add the Axis camera.
• Update firmware: Ensure both devices run the latest firmware for optimal performance.
• Configure ports: Open necessary ports (e.g., 80, 554) on the network for uninterrupted streaming.

Why This Matters / Understanding the Problem

Setting up a hybrid surveillance system with Axis IP cameras and a Hikvision NVR is a smart move for many homeowners and small businesses in 2026. While Hikvision cameras are designed to work seamlessly with their own NVRs, many users prefer the reliability, image quality, and cybersecurity features of Axis cameras. But here’s the catch: Hikvision NVRs don’t natively support Axis cameras out of the box.

This creates a common challenge: How to add Axis IP camera to Hikvision NVR in 2026 without spending extra on new equipment or losing video quality. Whether you’re upgrading an existing Hikvision system or integrating Axis cameras for specific areas (like entrances or parking lots), compatibility is key. The good news? It’s absolutely doable—with the right steps and a little patience.

By following this guide, you’ll learn how to bridge the gap between brands, maintain high-resolution footage, and avoid the headache of mismatched protocols. We’ll walk through the technical setup, explain why certain steps matter, and help you future-proof your security system. This isn’t just about connecting devices—it’s about building a reliable, cross-brand network that works for your needs.

What You Need

Before diving into the setup, gather these tools and materials. Having everything ready saves time and avoids mid-process surprises.

• Axis IP Camera (any model, but ensure it supports ONVIF—most do)
• Hikvision NVR (DS-76xx, DS-77xx, or newer models with ONVIF support)
• Ethernet cables (Cat5e or Cat6) for stable network connections
• Power supply or PoE switch (if not using PoE NVR ports)
• Router or network switch (to connect both devices to the same network)
• Laptop or desktop computer (for camera configuration)
• Web browser (Chrome, Firefox, or Edge) to access Axis camera settings
• ONVIF Device Manager (ODM) or Hikvision SADP tool (free downloads)

Optional but helpful: A network tester to verify cable integrity and a static IP address plan if managing multiple cameras. Most importantly, ensure your Hikvision NVR firmware is updated to the latest version (as of 2026)—this improves ONVIF compatibility, which is essential for how to add Axis IP camera to Hikvision NVR in 2026.

Pro Tip: Always check the Axis camera’s firmware too. Older versions may not fully support ONVIF Profile S or T, which are required for Hikvision NVRs.

Step-by-Step Guide to How to Add Axis IP Camera to Hikvision NVR in 2026

Step 1: Connect and Power Up the Axis Camera

Start by physically connecting your Axis camera to your network. Use an Ethernet cable to plug it into a PoE switch, router, or directly into a PoE port on your Hikvision NVR (if available).

If your camera isn’t PoE-powered, use the included power adapter. Once powered, wait 1–2 minutes for the camera to boot up. Look for status LEDs—steady green or blue usually means it’s online.

Now, connect your laptop to the same network. This is critical: both the camera and NVR must be on the same local network (same subnet) for discovery and configuration. For example, if your router uses 192.168.1.x, both devices should be in that range.

Warning: Don’t connect the camera to a separate VLAN or isolated network unless you know how to route traffic. Isolation prevents the NVR from detecting the camera.

Step 2: Assign a Static IP Address to the Axis Camera

Dynamic (DHCP) IPs can change, which breaks the connection between the camera and NVR. To avoid this, assign a static IP address to your Axis camera.

First, find the camera’s current IP using a tool like ONVIF Device Manager (ODM) or Hikvision SADP. Download ODM from SourceForge or use SADP (available on Hikvision’s official site). Open the tool and click “Search”—it will list all ONVIF-compatible devices on your network, including your Axis camera.

Note the camera’s current IP (e.g., 192.168.1.100). Now, access the camera’s web interface by typing that IP into your browser. Log in using the default credentials (usually admin / admin or check the camera’s manual). If you’ve changed them, use your custom login.

Navigate to Setup > System > Network > TCP/IP. Change the configuration from “Obtain IP address automatically” to “Use the following IP address.” Enter:

• IP Address: 192.168.1.101 (or any unused address in your network)
• Subnet Mask: 255.255.255.0 (common for home networks)
• Router Address: 192.168.1.1 (your router’s IP)

Click Save. The camera will restart. Wait a minute, then verify the new IP by pinging it from your laptop (open Command Prompt and type ping 192.168.1.101). A successful reply means it’s online.

Pro Tip: Use a consistent IP scheme. For example, assign Axis cameras 192.168.1.101–110, Hikvision cameras 192.168.1.201–210. This makes troubleshooting easier.

Step 3: Enable ONVIF on the Axis Camera

ONVIF is the universal language that lets different brands talk to each other. Your Hikvision NVR uses ONVIF to discover and connect to third-party cameras like Axis.

Back in the Axis camera’s web interface, go to Setup > System > Security > ONVIF. Here, you’ll see ONVIF settings. First, ensure ONVIF is enabled (toggle to “On”).

Next, create an ONVIF user. Click “Add” and enter:

• Username: onvif_user (or any name you’ll remember)
• Password: Use a strong password (8+ chars, mix of letters, numbers, symbols)
• User Group: Set to “Admin” or “Operator” (Admin gives full access; Operator limits control)

Click Save. This user account will be used by the Hikvision NVR to authenticate with the camera. Without it, the NVR can’t access the video stream.

Warning: Never skip this step. Even if the camera appears in the NVR, you’ll get “Authentication Failed” without a valid ONVIF user.

Step 4: Access the Hikvision NVR and Update Firmware

Before adding the camera, ensure your Hikvision NVR is up to date. Outdated firmware may lack full ONVIF support or have bugs that prevent third-party camera integration.

Connect a monitor and mouse to your NVR. Power it on and log in. Go to Main Menu > System > Maintenance > Upgrade. Click “Check” to see if a new firmware version is available. If yes, download it from Hikvision’s website and upload it via USB or network.

After upgrading, reboot the NVR. This ensures all compatibility features are active. While you’re here, check the NVR’s IP address under Network > General Settings. It should be in the same subnet as the Axis camera (e.g., 192.168.1.50).

Now, go to Camera > Camera Management. This is where you’ll add the Axis camera. Click “Add” or “+” to start the process.

Step 5: Discover and Add the Axis Camera via ONVIF

Hikvision NVRs have a built-in ONVIF camera search tool. Use it to find your Axis camera automatically.

In the Camera Management screen, click “Search”. The NVR scans the network for ONVIF devices. After a few seconds, you should see your Axis camera in the list—identified by its model name (e.g., “AXIS Q1615”) and IP address.

Select the camera and click “Add”. A pop-up will appear asking for:

• IP Address: Auto-filled (e.g., 192.168.1.101)
• Port: 80 (default for ONVIF)
• Username: onvif_user (from Step 3)
• Password: The password you set for the ONVIF user
• Protocol: ONVIF (should be selected by default)

Click “Test Connection”. If successful, you’ll see a green checkmark and “Connection successful.” If not, double-check the IP, port, and credentials.

Once connected, click “OK” to add the camera. It will appear in your camera list with a status of “Online.” The NVR will now stream video from the Axis camera, just like a native Hikvision one.

Pro Tip: If the camera doesn’t appear in the search, try manually entering its IP and ONVIF port (usually 80 or 8080). Sometimes firewalls or network filters block discovery.

Step 6: Configure Video and Recording Settings

Now that the camera is connected, optimize its settings for your needs. Click the camera in the list and go to “Edit” > “Video”.

Set the Stream Type to “Main Stream” for recording and “Sub Stream” for remote viewing. Choose resolutions based on your needs:

• Main Stream: 1080p (1920×1080) or 4MP for high detail
• Sub Stream: 720p or 480p to save bandwidth

Adjust the Frame Rate (25/30 fps for smooth motion) and Bitrate (higher = better quality, more storage). For a 4MP camera, 4096–6144 kbps is typical.

Next, go to “Recording” and enable Continuous Recording or Motion Detection. For motion, set sensitivity and detection areas to avoid false alarms (e.g., trees swaying).

Finally, check “Storage” to ensure the camera’s footage is saved to the NVR’s hard drive. You can view recordings later via playback or export them for evidence.

Step 7: Test and Monitor the Connection

After setup, test everything. Open the NVR’s live view—your Axis camera should show a clear, real-time feed. Check for:

• Smooth video (no stuttering or lag)
• Correct orientation (no upside-down or mirrored image)
• Proper night vision (if using IR mode)

Try accessing the NVR remotely using the Hik-Connect app or web portal. Add the camera to a multi-view layout to monitor it alongside Hikvision cameras.

Monitor the connection for 24–48 hours. If the camera goes offline, check:

• Network stability (use ping tests)
• IP address conflicts (no duplicate IPs)
• NVR storage space (full drives cause recording failures)

Warning: If the camera disconnects frequently, consider assigning it to a dedicated VLAN or using a managed switch with QoS to prioritize video traffic.

Pro Tips & Common Mistakes to Avoid

Even with the right steps, things can go wrong. Here’s how to avoid the most common pitfalls when learning how to add Axis IP camera to Hikvision NVR in 2026.

• Don’t skip firmware updates. Both the camera and NVR must be updated. Axis often releases patches for ONVIF compatibility, and Hikvision improves third-party support in newer firmware.
• Use strong ONVIF passwords. Default or weak passwords are security risks. Change them regularly, especially in public or commercial settings.
• Verify ONVIF Profile support. Axis cameras use Profile S (video) and Profile T (video + analytics). Ensure your Hikvision NVR supports both—older models may only support Profile S.
• Avoid DHCP for critical cameras. Static IPs prevent connection drops during network reboots.
• Don’t mix protocols. Use ONVIF only—avoid RTSP or proprietary protocols. RTSP may work but lacks features like motion detection and audio.
• Test before mounting. Set up the camera on a table first. Confirm it works with the NVR before installing it outdoors or in hard-to-reach places.

Real-Life Example: A small retail store tried to add an Axis camera but kept getting “Authentication Failed.” After checking, we found the ONVIF user had “Operator” rights instead of “Admin.” Upgrading the user group fixed it instantly.

FAQs About How to Add Axis IP Camera to Hikvision NVR in 2026

Here are the most common questions—answered with practical, no-nonsense advice.

Q1: Can I add multiple Axis cameras to one Hikvision NVR?
Yes! The process is the same for each camera. Just assign unique static IPs and ONVIF users. Most Hikvision NVRs support 4, 8, 16, or 32 channels—check your model’s specs.

Q2: Why isn’t my Axis camera showing up in the NVR search?
Common causes: (1) Camera and NVR on different subnets, (2) Firewall blocking ONVIF (port 80/8080), (3) ONVIF disabled on the camera, or (4) IP conflict. Use a network scanner like Wireshark or Advanced IP Scanner to diagnose.

Q3: Will adding an Axis camera reduce recording quality?
No—if configured correctly. Set the main stream to the camera’s maximum resolution (e.g., 4MP). The NVR will record at that quality, just like a native camera.

Q4: Can I use the Axis camera’s built-in motion detection with the Hikvision NVR?
Yes, but it’s better to use the NVR’s detection. The NVR can analyze the Axis stream and trigger alerts, recordings, or notifications. This centralizes control and works better with Hikvision’s AI features (like face detection).

Q5: What if my Hikvision NVR doesn’t have an ONVIF option?
Update the firmware first. If the option still isn’t there, your NVR may be an older model without third-party support. Consider upgrading to a newer Hikvision NVR (DS-76xx or higher).

Q6: Is it safe to mix brands?
Absolutely. ONVIF is an industry standard used by 100+ brands. As long as both devices support ONVIF Profile S/T, the integration is secure and reliable.

Q7: Can I access the Axis camera’s settings through the NVR?
No. You must use the camera’s web interface for settings like focus, zoom, or IR mode. The NVR only manages video streaming, recording, and alerts.

Final Thoughts

Adding an Axis IP camera to a Hikvision NVR isn’t just possible—it’s a smart way to build a flexible, high-performance security system in 2026. By following this guide on how to add Axis IP camera to Hikvision NVR in 2026, you’ve learned how to overcome compatibility issues, ensure stable connections, and maintain top-quality surveillance.

Remember: the key is ONVIF. It’s the bridge between brands, and with proper setup, your Axis and Hikvision devices will work together seamlessly. Whether you’re monitoring a home, office, or store, this hybrid approach gives you the best of both worlds—Axis’s camera excellence and Hikvision’s robust recording and management tools.

Now that you’ve got the steps, go ahead and set it up. Test thoroughly, document your IP addresses, and keep your firmware updated. In a few years, when you expand your system, you’ll thank yourself for building a scalable, cross-brand network from the start. Stay secure, stay smart!

“`
