Assigning an IP address to your Axis camera is essential for connecting it to your network and accessing its features remotely. This guide walks you through the entire process—from physical setup to final configuration—using tools like Axis Device Manager or web interface. Whether you’re setting up a new camera or replacing a faulty one, this method ensures reliable connectivity and optimal performance.

# How to Assign IP Address to Axis Camera: Complete Step-by-Step Guide

Setting up an IP camera, especially a professional-grade model like those from Axis Communications, involves more than just plugging it in. One of the most critical steps in the installation process is assigning an IP address to your Axis camera. Without a valid IP address, the camera cannot communicate over your local network, making remote viewing, recording, and management impossible.

In this comprehensive guide, we’ll walk you through every step needed to successfully assign an IP address to your Axis camera—whether it’s a brand-new device or one that needs reconfiguration. You’ll learn how to use Axis Device Manager, configure static vs. dynamic IPs, troubleshoot connectivity issues, and ensure long-term network stability.

By the end of this article, you’ll be confident in setting up your Axis camera from scratch and maintaining its network presence.

—

## What Is an IP Address and Why Does It Matter?

Before diving into the technical steps, let’s clarify what an IP address is and why it’s crucial for your Axis camera.

An IP address (Internet Protocol address) is a numerical label assigned to each device connected to a computer network. Think of it as your camera’s unique home address on the network. Just like how you need a street address to receive mail, your camera needs an IP address to send and receive data.

Axis cameras typically come with a default IP address (like 192.168.0.90), but if multiple devices share the same subnet or if the camera is reset, you may need to manually assign or change its IP address.

Without a properly configured IP, you won’t be able to:
– Access the camera’s live feed via a web browser.
– Use Axis companion software or surveillance platforms.
– Integrate the camera into your NVR or video management system.

—

## Prerequisites Before Assigning an IP Address

Before you begin, make sure you have the following:

### 1. Physical Connection
– Connect your Axis camera to your router or switch using an Ethernet cable.
– Ensure the camera is powered on (use PoE if supported, or connect via included power adapter).

### 2. Computer on the Same Network
– Your computer must be connected to the same local network as the camera.
– Avoid using a different subnet or VLAN unless you’re configuring advanced routing.

### 3. Axis Device Manager
– Download and install Axis Device Manager from Axis’ official website. This tool simplifies discovery and configuration.

### 4. Default Login Credentials
– Most Axis cameras use default username: root, password: pass.
– Keep these handy during initial setup.

### 5. Static IP Planning
– Decide whether you want a static (fixed) IP or rely on DHCP (dynamic).
– For most users, static IPs are recommended for reliability.

—

## Step-by-Step: Assign IP Address Using Axis Device Manager

This is the easiest and most reliable method for assigning an IP address to an Axis camera.

Step 1: Install Axis Device Manager

Visit the Axis website and download the latest version of Axis Device Manager. It’s available for Windows and macOS.

  • Run the installer and follow the prompts.
  • Launch the application after installation.

Step 2: Connect Camera and Computer

Ensure both your computer and Axis camera are on the same network.

  • Connect the camera via Ethernet to your router or switch.
  • Power on the camera.
  • Make sure your computer is also connected to the same network (Wi-Fi or wired).

Step 3: Scan for Devices

In Axis Device Manager, click “Search” to scan the network.

  • The tool will automatically detect Axis cameras within the current subnet.
  • If multiple cameras appear, note their default IP addresses (e.g., 192.168.0.90).

Step 4: Select and Configure the Camera

Double-click the detected camera to open its configuration window.

  • Go to the Network > TCP/IP tab.
  • Choose between Static IP or DHCP.

Step 5: Set Static IP Address (Recommended)

For stable access, use a static IP:

  • Select Static IP under the IP configuration.
  • Enter an IP address not already in use (e.g., 192.168.1.100).
  • Set Subnet mask: 255.255.255.0
  • Default gateway: Your router’s IP (e.g., 192.168.1.1)
  • Primary DNS: Often same as gateway, or use public DNS like 8.8.8.8
  • Click Apply to save changes.

Step 6: Reconnect and Test

After applying the settings, the camera will reboot with the new IP.

  • Wait 30–60 seconds for it to restart.
  • Try accessing it via a web browser: http://[new-IP]
  • Log in using default credentials.

—

## Alternative Method: Manual IP Assignment via Web Interface

If you prefer not to use Axis Device Manager, you can manually assign the IP through the camera’s built-in web server.

Step 1: Find Current IP (If Known)

Check your router’s connected devices list to see if the camera has a temporary IP.

Step 2: Access Camera via Browser

Type the known IP into your browser’s address bar.

  • If you don’t know the IP, try common defaults like 192.168.0.90 or 192.168.1.90.

Step 3: Log In

Enter the default login: Username: root, Password: pass.

Step 4: Navigate to Network Settings

Go to Setup > System > Network.

Step 5: Change IP Configuration

Under TCP/IP settings:

  • Select Manual (static) IP assignment.
  • Input desired IP, subnet, gateway, and DNS.
  • Save and reboot when prompted.

—

## Choosing Between Static and Dynamic IP Addresses

You might wonder: should I use a static or dynamic IP for my Axis camera?

| Option | Pros | Cons |
|——-|——|——|
| **Static IP** | Always reachable; no IP changes; ideal for remote access | Requires manual setup; risk of IP conflict if misconfigured |
| **Dynamic IP (DHCP)** | Automatic setup; easy to manage | IP may change after reboot; harder to locate |

Recommendation:

For surveillance systems, a static IP is strongly recommended. This ensures your NVR, mobile app, or monitoring software always knows where to find the camera.

If you choose DHCP, consider reserving the IP in your router’s settings so it always assigns the same address to the camera’s MAC address.

—

## Troubleshooting Common Issues When Assigning IP Address

Even with careful setup, you might encounter problems. Here’s how to fix them.

Issue 1: Camera Not Detected by Axis Device Manager

Possible causes: Wrong subnet, firewall blocking, or incorrect cable.

  • Check that all devices are on the same network segment.
  • Disable firewalls temporarily for testing.
  • Try a different Ethernet cable or port.

Issue 2: Can’t Access Camera After IP Assignment

Symptoms: Browser shows “Connection refused” or “Page not found.”

  • Verify the IP address is correct.
  • Ensure no IP conflict exists (check router DHCP table).
  • Confirm the camera is powered and connected.

Issue 3: Login Fails After Setup

Solution: Reset the camera to factory defaults if you’ve forgotten the password.

  • Locate the reset button (usually small hole on the device).
  • Press and hold for 10+ seconds until LED blinks.
  • Reconfigure using Axis Device Manager.

Issue 4: IP Conflict Errors

If two devices have the same IP, your network becomes unstable.

  • Check your router’s connected devices list.
  • Manually assign unique IPs to avoid overlap.

—

## Advanced Tips for Professional Installations

For enterprise or large-scale deployments, consider these best practices:

Use VLAN Segmentation

Place cameras on a separate VLAN to improve security and reduce bandwidth congestion.

  • Configure your managed switch to tag camera traffic.
  • Limit inter-VLAN routing unless necessary.

Enable HTTPS and Strong Passwords

Protect access by enabling encrypted connections and changing default credentials immediately.

Document Your Network Layout

Keep a spreadsheet of camera IPs, locations, MAC addresses, and firmware versions for easy maintenance.

—

## Conclusion

Assigning an IP address to your Axis camera doesn’t have to be intimidating. With the right tools and clear steps—especially using Axis Device Manager—you can get your camera online quickly and reliably.

Whether you’re building a home security system or managing a commercial surveillance network, understanding how to assign and manage IP addresses is a foundational skill. Remember to use static IPs for consistency, keep firmware updated, and always double-check your network settings.

Once your Axis camera is properly networked, you’ll enjoy high-quality video feeds, remote access, and seamless integration with recording and analytics platforms.

—

Quick Answers to Common Questions

Tip/Question?

Answer: Yes, you can assign an IP address even if the camera doesn’t have a display. Use Axis Device Manager or access it via a web browser once you know its default IP.

Tip/Question?

Answer: Always assign a static IP within your router’s range (e.g., 192.168.1.x) to avoid IP conflicts and ensure consistent access.

Tip/Question?

Answer: If your Axis camera uses PoE, ensure your switch or injector supports IEEE 802.3af/at standards to provide sufficient power and data simultaneously.

Tip/Question?

Answer: After assigning the IP, test connectivity by pinging the camera from your computer using ping [camera-IP] in Command Prompt or Terminal.

Tip/Question?

Answer: For remote access without a public IP, consider using Axis Companion Cloud or ONVIF-compatible services like Blue Iris or Milestone for secure streaming.
