How to Change Hikvision Camera Ip Address

How to Change Hikvision Camera Ip Address

by

Changing the IP address of a Hikvision camera is essential for network reconfiguration, security updates, or resolving connectivity problems. This guide walks you through accessing your camera via its current IP, using the Hikvision software or web interface, and updating the network settings correctly. With clear steps and troubleshooting tips, you’ll ensure your Hikvision camera stays online and accessible on your network.

Quick Answers to Common Questions

Can I change my Hikvision camera’s IP while it’s recording?

Yes, but it’s safer to do so during low activity or after stopping recording. Some models may briefly interrupt live feed during reboot.

What if I lose access to my camera after changing the IP?

Try reconnecting using the new IP in your browser. If that fails, scan your network to confirm the IP was updated, or reset the camera to factory defaults.

Is it better to use DHCP or a static IP?

Static IPs are recommended for cameras because they ensure consistent access. Use DHCP only if your router has DHCP reservation for the device.

Do I need special software to change the IP?

No. The web interface works on any modern browser. Hikvision iVMS-4200 is optional and helpful for managing multiple cameras.

Will changing the IP affect video quality?

No. The IP change only affects network addressing. Video resolution, bitrate, and quality remain unchanged.

How to Change Hikvision Camera IP Address: A Complete Step-by-Step Guide

If you’re managing multiple IP cameras on your network—especially Hikvision models—you may need to change the IP address of one or more devices. Whether it’s to avoid conflicts, reorganize your network, or fix connection issues, updating the IP address is a routine but important task. This guide will walk you through every step of changing a Hikvision camera’s IP address using both the web interface and the official Hikvision software. We’ll also cover troubleshooting tips and best practices to keep your system running smoothly.

By the end of this article, you’ll know exactly how to access your camera, update its network settings, and ensure it remains accessible. No technical jargon—just clear, simple instructions anyone can follow.

Why You Might Need to Change Your Hikvision Camera’s IP Address

There are several practical reasons why you might need to change the IP address of your Hikvision camera:

How to Change Hikvision Camera Ip Address

Visual guide about How to Change Hikvision Camera Ip Address

Image source: blockchain-council.org

  • Network Reconfiguration: When setting up multiple cameras, each must have a unique IP. If two cameras share the same IP, they’ll conflict, causing one or both to go offline.
  • Security Updates: Changing the IP helps prevent unauthorized access if an old address becomes exposed or if you suspect a breach.
  • Router Changes: If your router’s DHCP range changes, previously assigned IPs may no longer be valid.
  • Troubleshooting Connectivity: Sometimes, a camera loses its IP due to network instability and needs to be reassigned.
  • Device Replacement: If you’re replacing a faulty camera with a new one, you may want to reuse the same IP for consistency.

Regardless of the reason, the process is straightforward once you know where to look.

Gather What You Need Before Starting

Before you begin, make sure you have the following:

  • Computer connected to the same network: The device you use to access the camera should be on the same local network.
  • Current IP address of the camera: This is essential for logging in. If you don’t know it, we’ll show you how to find it.
  • Web browser or Hikvision iVMS-4200 software: Either method works, but the web interface gives you full control.
  • Administrator credentials: Default login is usually admin/password unless changed.
  • New IP address and subnet mask: For example, 192.168.1.150 with subnet 255.255.255.0.
  • Optional: Router access: To set up DHCP reservation later.

Tip: Find Your Camera’s Current IP Address

If you don’t know your camera’s current IP, use a tool like Advanced IP Scanner (free) or check your router’s connected devices list. Look for the Hikvision model under active devices.

Method 1: Change IP Address Using the Web Interface

The most direct way to change your Hikvision camera’s IP address is through its built-in web interface. This method gives you full control over network settings and doesn’t require additional software.

Step 1: Access the Camera’s Login Page

  1. Open your web browser (Chrome, Firefox, Edge, etc.).
  2. In the address bar, type the camera’s current IP address (e.g., http://192.168.1.64) and press Enter.
  3. You’ll see the login screen. Enter the username and password:
    • Default: admin / password
    • If you’ve changed these, use your custom credentials.
  4. Click Login.

Step 2: Navigate to Network Settings

  1. Once logged in, go to the top menu and click Configuration.
  2. In the left sidebar, expand System, then select Network.
  3. Under the TCP/IP tab, you’ll see the current IP settings.

Step 3: Modify the IP Configuration

  1. Change the IP Version to IPv4 if not already selected.
  2. Set Obtain IP automatically (DHCP) to OFF if you want a static IP.
  3. Enter the following details:
    • IP Address: New IP (e.g., 192.168.1.150)
    • Subnet Mask: Usually 255.255.255.0
    • Default Gateway: Your router’s IP (e.g., 192.168.1.1)
    • Preferred DNS: Optional, but 8.8.8.8 is reliable.
  4. Click Apply to save changes.

Step 4: Log Back In with the New IP

  1. Close the current browser tab.
  2. Open a new tab and go to the new IP address (e.g., http://192.168.1.150).
  3. Log in again with your credentials.
  4. Confirm the settings are correct.

Method 2: Change IP Address Using Hikvision iVMS-4200 Software

If you prefer using desktop software, Hikvision’s iVMS-4200 allows you to manage multiple cameras from one interface. This is especially useful for businesses or larger setups.

Step 1: Install and Open iVMS-4200

  1. Download iVMS-4200 from the official Hikvision website.
  2. Install and launch the program.
  3. Log in using your camera’s credentials (or create a local user account).

Step 2: Add Your Camera

  1. Click Add Device in the toolbar.
  2. Enter the camera’s current IP, port (default 8000), username, and password.
  3. Check Add as online device and click OK.
  4. Wait for the status to show as Online.

Step 3: Access Camera Settings

  1. Right-click the camera name in the device list.
  2. Select Device Manager.
  3. In the window that opens, go to Network > Basic Parameters.

Step 4: Update the IP Address

  1. Uncheck Enable DHCP if currently enabled.
  2. Enter the new static IP, subnet mask, and gateway.
  3. Click Save.
  4. Reboot the camera when prompted.

Step 5: Reconnect Using the New IP

  1. In iVMS-4200, remove the old device entry.
  2. Add a new device using the updated IP.
  3. Verify it connects successfully.

Practical Tips for Managing Hikvision Camera IPs

To avoid confusion and downtime, follow these best practices:

  • Use consistent subnets: All devices should be in the same range (e.g., 192.168.1.x).
  • Avoid common IPs: Don’t use .1 or .254 unless necessary; reserve them for routers and gateways.
  • Label cameras physically: Write the IP and location on the device or in a spreadsheet.
  • Update documentation: Keep a record of all camera IPs, passwords, and locations.
  • Test after changes: Always verify access immediately after updating the IP.

Troubleshooting Common Issues

Even with careful steps, things can go wrong. Here’s how to fix common problems.

Problem: Can’t Access Camera After IP Change

This is the most frequent issue. Possible causes include:

  • Wrong new IP: Double-check the IP, subnet, and gateway.
  • Firewall blocking: Temporarily disable firewall or antivirus to test.
  • Browser cache: Clear cache or try incognito mode.
  • Camera not rebooting: Some models need a power cycle to apply changes.

Problem: IP Conflict Error

If another device uses the new IP, your camera will fail to connect. Solution:

  1. Scan your network for active devices.
  2. Assign a free IP from your DHCP pool.
  3. Alternatively, reserve the IP in your router.

Problem: Login Credentials Forgotten

Reset the camera to factory defaults:

  1. Locate the reset button (usually small and recessed).
  2. Press and hold for 10–15 seconds using a paperclip.
  3. Reconfigure the IP and login (default: admin/password).

How to Prevent Future IP Conflicts

The easiest way to avoid IP changes is to let your router manage assignments—but even then, cameras can get new IPs. Instead, use DHCP reservation:

Steps to Set Up DHCP Reservation on Your Router

  1. Log into your router’s admin panel (usually 192.168.1.1).
  2. Go to LAN > DHCP Server.
  3. Find the camera’s MAC address (available in the camera’s network settings).
  4. Assign a reserved IP based on the MAC.
  5. Save and restart the router if needed.

Now, every time the camera boots, it will receive the same IP.

Final Thoughts: Keep Your System Secure and Organized

Changing your Hikvision camera’s IP address is a simple but vital task for maintaining a stable and secure surveillance system. Whether you’re reconfiguring for expansion, fixing connectivity, or enhancing security, knowing how to do it correctly saves time and frustration. Always remember to test your changes and document everything. With tools like DHCP reservations and proper labeling, you can keep your network clean and efficient.

For advanced users, consider integrating cameras with VMS platforms like Milestone or Blue Iris for centralized management. And never forget to change default passwords—security starts at login.

By following this guide, you’ve taken a key step toward professional-grade network camera management.
