How to Disable Video Matrix in Dahua DVR
If you’re managing a Dahua DVR system, you may have encountered the term “video matrix.” This feature allows you to control how multiple camera feeds are displayed on your monitor—such as showing four cameras in a 2×2 grid or switching between full-screen views. While useful, the video matrix can sometimes cause performance issues, especially on older or lower-end DVR models. It may slow down the interface, cause lag, or interfere with custom display preferences.
In this comprehensive guide, we’ll walk you through the process of how to disable video matrix in Dahua DVR step by step. Whether you’re a security technician, a business owner managing your own surveillance system, or a home user looking to optimize your setup, this guide will help you turn off the video matrix safely and effectively. You’ll learn how to access the correct settings, understand why you might want to disable it, and troubleshoot common issues that may arise.
By the end of this guide, you’ll not only know how to disable the video matrix but also understand when and why it’s beneficial to do so. We’ll cover multiple access methods—including the local DVR interface, web browser access, and mobile apps—so you can choose the option that works best for your setup.
Let’s get started.
What Is the Video Matrix in a Dahua DVR?
Visual guide about How to Disable Video Matrix in Dahua Dvr
Image source: 1.bp.blogspot.com
Before diving into the “how,” it’s important to understand the “what.” The video matrix in a Dahua DVR is a display management feature that determines how video feeds from connected cameras are shown on your monitor. It allows you to customize the layout of your surveillance screen—such as viewing one camera at a time, splitting the screen into quadrants, or creating custom multi-screen arrangements.
For example, if you have eight cameras connected, the video matrix lets you choose whether to display all eight at once in a grid, cycle through them automatically, or manually switch between full-screen views. This flexibility is great for monitoring large areas, but it comes with a cost: the DVR must process and manage multiple video streams simultaneously, which can strain system resources.
On high-end Dahua DVRs with powerful processors, this isn’t usually a problem. But on entry-level or older models, enabling the video matrix can lead to:
- Delayed video playback
- Lagging mouse cursor or menu navigation
- Reduced frame rates on live feeds
- Increased CPU usage, potentially affecting recording quality
Disabling the video matrix simplifies the display output. Instead of managing complex layouts, the DVR sends a single, clean video feed to the monitor—often just the main camera view or a basic split-screen that you define manually. This reduces processing overhead and can significantly improve system responsiveness.
Why Disable the Video Matrix?
You might be wondering: if the video matrix offers flexibility, why would anyone want to turn it off? The answer lies in performance, simplicity, and specific use cases.
Improved System Performance
As mentioned earlier, the video matrix requires the DVR to process multiple video streams at once. This can slow down the system, especially if you have many cameras or high-resolution feeds (like 4MP or 8MP). Disabling the matrix reduces the processing load, leading to smoother navigation, faster menu responses, and more reliable recording.
Simplified Monitoring
Some users prefer a straightforward display—such as viewing one camera at a time or using a simple 4-way split. If you don’t need advanced layout options, disabling the matrix can eliminate unnecessary complexity. It also prevents accidental layout changes that might confuse less experienced users.
Troubleshooting Display Issues
If your monitor shows a black screen, flickering, or incorrect camera layouts, the video matrix might be misconfigured. Disabling it can help isolate the problem. For example, if the DVR works fine with the matrix off but glitches when it’s on, you’ll know the issue is related to display processing—not the cameras or cables.
Compatibility with External Monitors
Some third-party monitors or video switchers don’t work well with Dahua’s matrix output. Disabling the matrix and using a direct video feed can improve compatibility and image quality.
Energy and Resource Efficiency
On systems with limited power or cooling, reducing processing tasks like matrix management can help extend hardware lifespan and reduce heat buildup.
Prerequisites Before Disabling the Video Matrix
Before making any changes, it’s important to prepare your system to avoid unintended consequences.
Check Your DVR Model and Firmware
Not all Dahua DVRs handle the video matrix the same way. Older models (like the Dahua Lite series) may have limited options, while newer XVRs (Hybrid DVRs) offer more advanced settings. Check your model number (usually on the back or bottom of the unit) and ensure your firmware is up to date. You can update firmware via the DVR’s menu or using Dahua’s Firmware Upgrade Tool.
Backup Your Current Configuration
Before disabling the matrix, go to Main Menu > System > Maintenance > Backup and save your current settings to a USB drive. This allows you to restore your original configuration if something goes wrong.
Ensure Physical Access or Remote Connectivity
You’ll need to access the DVR’s interface. This can be done:
- Directly via a monitor and mouse connected to the DVR
- Remotely via a web browser (using the DVR’s IP address)
- Through the Dahua Smart PSS software on a PC
- Using the DMSS mobile app on a smartphone or tablet
Make sure you know the DVR’s IP address, username, and password. Default credentials are often admin/admin or admin/123456, but these should be changed for security.
Verify Camera Connections
Ensure all cameras are properly connected and functioning. Disabling the matrix won’t affect recording, but if cameras aren’t working, you’ll need to fix those issues first.
Step-by-Step Guide: Disabling Video Matrix via Local DVR Interface
This is the most direct method and works on all Dahua DVR models with a physical interface.
Step 1: Access the Main Menu
Connect a monitor and mouse to your Dahua DVR. Power it on and wait for the system to boot. Once the live view appears, right-click anywhere on the screen to open the context menu. Select Main Menu.
Step 2: Navigate to Display Settings
In the main menu, use the arrow keys or mouse to go to the Display tab. This section controls monitor output, resolution, and layout settings.
Step 3: Locate the Video Matrix Option
Look for a submenu labeled Video Matrix, Matrix Setup, or Screen Layout. The exact name varies by model. For example:
- Dahua XVR: Display > Video Matrix
- Dahua Lite: Display > Output Mode
- Dahua Pro: Display > Layout
Step 4: Disable the Matrix
Once inside the matrix settings, you’ll see options like:
- Enable/Disable
- Matrix Mode (e.g., 1×1, 2×2, 3×3)
- Auto Switch Interval
Find the Enable toggle or checkbox and set it to Off or Disabled. Some models may require you to select a different output mode, such as Single Screen or Manual Switch.
Step 5: Apply and Save Changes
Click Apply or Save to confirm your settings. The DVR may restart the display output. Wait a few seconds for the screen to refresh.
Step 6: Verify the Result
Check the live view. You should now see a simplified display—likely a single camera feed or a basic split-screen that you can manually control. Use the mouse or remote to switch between cameras and ensure everything works as expected.
Disabling Video Matrix via Web Browser (Remote Access)
If you can’t access the DVR physically, you can disable the matrix remotely using a web browser.
Step 1: Find the DVR’s IP Address
On the DVR, go to Main Menu > Network > TCP/IP and note the IP address. Alternatively, use the Dahua Config Tool to scan your network for Dahua devices.
Step 2: Open a Web Browser
On a computer connected to the same network, open Chrome, Firefox, or Edge. Type the DVR’s IP address into the address bar and press Enter.
Step 3: Log In
Enter your username and password. If this is your first time, you may need to install the Dahua Web Plugin. Follow the on-screen prompts to complete the installation.
Step 4: Access Display Settings
Once logged in, click on the Setup or Configuration tab. Navigate to Display > Video Matrix or a similar option.
Step 5: Disable the Matrix
Uncheck the Enable Video Matrix box or select Disabled from the dropdown menu. Adjust any related settings, such as output mode or resolution.
Step 6: Save and Refresh
Click Save. The changes may take effect immediately, or you may need to refresh the page. Test the live view to confirm the matrix is off.
Using Dahua Smart PSS Software
Dahua Smart PSS (Professional Surveillance System) is a free PC application that lets you manage multiple DVRs from one interface.
Step 1: Install and Open Smart PSS
Download Smart PSS from the official Dahua website and install it on your computer. Launch the program.
Step 2: Add Your DVR
Click Device Management and add your DVR by entering its IP address, port, username, and password.
Step 3: Access Device Settings
Right-click on the DVR in the device list and select Remote Configuration.
Step 4: Navigate to Display Settings
Go to Display > Video Matrix and disable the feature as described earlier.
Step 5: Apply Changes
Click Save and close the configuration window. The DVR will apply the new settings automatically.
Using the DMSS Mobile App
The Dahua Mobile Surveillance System (DMSS) app allows you to manage your DVR from a smartphone or tablet.
Step 1: Install DMSS
Download DMSS from the App Store (iOS) or Google Play (Android).
Step 2: Add Your DVR
Open the app, tap the “+” icon, and add your DVR using its serial number, IP address, or QR code.
Step 3: Access Device Settings
Tap on the DVR name, then go to Settings > Device Settings > Display.
Step 4: Disable Video Matrix
Look for the video matrix option and toggle it off. Note that not all DVR models support matrix control via mobile app—this feature is more common on newer systems.
Step 5: Confirm Changes
Exit the settings and check the live view. The display should now be simplified.
Troubleshooting Common Issues
Even with careful steps, you might run into problems. Here’s how to fix the most common ones.
Black Screen After Disabling Matrix
If your monitor goes black after disabling the matrix, the DVR may be outputting a signal the monitor can’t display. Try:
- Pressing the Menu button on the DVR remote or using the mouse to bring up the interface
- Reconnecting the HDMI or VGA cable
- Switching to a different output port (e.g., from HDMI to VGA)
- Rebooting the DVR
Settings Not Saving
If changes don’t persist after reboot, check:
- User permissions—ensure you’re logged in as admin
- Firmware version—update if outdated
- Power supply—use a stable power source
Cameras Not Displaying Correctly
If some cameras are missing or showing incorrect feeds:
- Verify camera connections and power
- Check channel assignments in Camera > Channel Title
- Re-enable the matrix temporarily to reset layouts, then disable again
Remote Access Not Working
If you can’t access the DVR remotely:
- Confirm the DVR is on the same network
- Check firewall and router settings
- Ensure port forwarding is set up correctly (default port 80 or 8000)
- Use the Dahua Config Tool to verify connectivity
Best Practices After Disabling the Video Matrix
Once the matrix is disabled, follow these tips to maintain optimal performance:
Set a Default View
Manually configure your preferred display layout—such as a 4-way split or single camera view—and save it as the default.
Use PTZ Controls Wisely
If you have PTZ (pan-tilt-zoom) cameras, ensure their controls are accessible even without the matrix.
Monitor System Performance
Check CPU and memory usage in System > Maintenance > System Info. You should see reduced load after disabling the matrix.
Update Firmware Regularly
Dahua frequently releases updates that improve stability and add features. Keep your DVR up to date.
Document Your Changes
Keep a record of configuration changes, including when and why you disabled the matrix. This helps with future troubleshooting.
Conclusion
Disabling the video matrix in your Dahua DVR is a simple yet powerful way to improve system performance, simplify monitoring, and resolve display issues. Whether you’re using the local interface, web browser, Smart PSS, or DMSS app, the process is straightforward once you know where to look.
By following this guide, you’ve learned not only how to disable the video matrix but also why it matters. You now have the knowledge to optimize your surveillance setup for your specific needs—whether that’s smoother operation, easier navigation, or better compatibility with external devices.
Remember to always back up your settings before making changes, test thoroughly afterward, and consult your user manual if you encounter model-specific differences. With the video matrix disabled, your Dahua DVR can run more efficiently, giving you peace of mind and a clearer view of what matters most.
