Finding the IP address of a CCTV camera is essential for remote viewing and system management. This guide walks you through multiple methods—from using software tools to checking router settings—ensuring you can access your surveillance system efficiently. Whether you’re setting up a new camera or troubleshooting connectivity, these simple steps will help you get started.

Quick Answers to Common Questions

Tip/Question?

Answer: Yes, most modern CCTV cameras support ONVIF protocol, which allows compatible software to discover and connect to them automatically without needing the IP address first.

Tip/Question?

Answer: Always write down the IP address and save it in a secure place—either digitally in an encrypted note or physically on paper. This prevents future confusion.

Tip/Question?

Answer: If your camera uses DHCP and keeps changing IPs, reserve a fixed IP in your router’s DHCP settings instead of setting a static IP on the camera—this avoids conflicts.

Tip/Question?

Answer: Never leave default usernames and passwords unchanged. Change them immediately after setup to prevent unauthorized access to your camera feed.

Tip/Question?

Answer: Use a wired connection (Ethernet) for critical cameras whenever possible. Wireless signals can be weaker and more prone to interference or hacking attempts.

How to Get IP Address of CCTV Camera: A Complete Guide

If you’ve installed a CCTV camera at home or in your office, one of the first things you’ll need is its IP address. Without it, you won’t be able to connect to the camera remotely, view live footage, or configure settings through a web browser or mobile app. Fortunately, finding the IP address doesn’t have to be complicated. With the right tools and a few simple steps, you can locate it quickly and securely.

This guide will walk you through everything you need to know about discovering the IP address of your CCTV camera—whether it’s a wired, wireless, or PoE-powered model. We’ll cover both beginner-friendly methods and more advanced techniques for tech-savvy users. By the end, you’ll be confident in locating your camera’s IP address and managing your surveillance system like a pro.

Why You Need the IP Address of Your CCTV Camera

The IP address is like a digital street address for your CCTV camera. It allows communication between the camera and other devices on your local network—like your computer, smartphone, or NVR (Network Video Recorder). Without this unique identifier, your devices won’t know where to send data or how to retrieve video feeds.

How to Get Ip Address of Cctv Camera

Visual guide about How to Get Ip Address of Cctv Camera

Image source: pic3.zhimg.com

Common reasons to find the IP address include:

  • Accessing the camera’s live feed remotely via a web browser
  • Configuring motion detection or recording schedules
  • Updating the camera’s firmware
  • Troubleshooting connection issues
  • Adding the camera to a surveillance software platform like Blue Iris or iSpy

In short, knowing your camera’s IP address is the gateway to full control over your security system.

Step 1: Check the Camera Label or Manual

The easiest way to find the IP address is by looking directly on the camera or in its documentation. Many CCTV cameras come pre-configured with a default IP address, especially during initial setup.

Look for a Sticker on the Camera Body

Many manufacturers print key details—including the IP address, username, and password—on a label underneath the camera lens or on the side. Common formats include:

  • 192.168.1.100
  • Default Gateway: 192.168.0.1
  • IP: 192.168.1.64

If you see something like “Default IP: 192.168.1.108,” that’s your answer. Write it down—you’ll use it soon.

Review the User Manual or Quick Start Guide

If the sticker isn’t visible or has worn off, check the original packaging or download the manual from the manufacturer’s website. Most manuals list default login credentials and network settings, including the IP address range used by the camera.

For example, Hikvision cameras often use IPs in the range 192.168.1.x, while Dahua cameras may start at 192.168.0.x. Knowing the brand helps narrow down possible addresses.

Step 2: Use an IP Scanner Tool

If you can’t find the IP address on the camera or manual, the next best option is to scan your network. These tools detect all devices connected to your Wi-Fi or Ethernet network and display their IP addresses, hostnames, and sometimes MAC addresses.

Recommended Tools

  • Fing (Free, iOS/Android) – Very user-friendly; instantly shows connected devices.
  • Angry IP Scanner (Windows/macOS/Linux) – Open-source and fast; great for scanning large networks.
  • nmap (Advanced users) – Command-line tool with powerful scanning options.

How to Use Fing

  1. Download and install Fing on your smartphone or computer.
  2. Open the app and tap “Scan Network.”
  3. Wait for results—it usually takes 10–30 seconds.
  4. Look for entries labeled “Camera,” “IPC,” or the brand name (e.g., “Hikvision” or “Dahua”).
  5. Note the IP address listed next to it.

Tip: If multiple cameras are present, check each one’s model number or location to identify the correct device.

Using Angry IP Scanner

  1. Launch Angry IP Scanner.
  2. Enter your router’s IP address (commonly 192.168.1.1 or 192.168.0.1).
  3. Set the port range (default is 80 for HTTP access).
  4. Click “Start.”
  5. Browse results and look for open ports associated with camera services.

These scanners are especially helpful when you have multiple devices and aren’t sure which one is your camera.

Step 3: Access Your Router’s Admin Panel

Your router acts as the central hub for all devices on your network. By logging into its admin interface, you can see every device connected—including your CCTV camera—and pull up their assigned IP addresses.

Steps to Find Connected Devices

  1. Connect to your home network via Wi-Fi or Ethernet.
  2. Type your router’s default gateway address into a web browser. Common defaults:
    • 192.168.1.1
    • 192.168.0.1
    • 10.0.0.1
  3. Log in using your admin username and password (often found on the router label or in the manual).
  4. Navigate to sections like:
    • “Connected Devices”
    • “Device List”
    • “DHCP Client List”
  5. Scroll through the list and look for entries matching your camera brand or model.

Example: If you see “Hikvision IPC-2120” with IP 192.168.1.105, that’s your camera!

Note: Some routers group devices by type. Look for categories like “IP Cameras” or “Security Devices.”

Step 4: Use the Camera’s Web Interface

Once you have a suspected IP address, try opening it in a web browser. This confirms whether the camera is accessible and lets you log in to its configuration page.

How to Access the Camera via Browser

  1. Open Chrome, Firefox, or Edge.
  2. Type the IP address (e.g., http://192.168.1.100) into the address bar.
  3. Press Enter.
  4. When prompted, enter the default username and password (often admin/admin or admin/12345).

If the login page loads, you’ve successfully found the IP address! From here, you can change settings, update firmware, or set up remote access.

💡 Pro Tip: Bookmark the IP address after logging in so you don’t lose it later.

Step 5: Assign Static IP Addresses (Optional but Recommended)

Dynamic IP addresses (assigned automatically by your router) can change over time, making it hard to remember your camera’s address. To prevent this, assign a static IP address to your camera.

Why Use a Static IP?

  • Ensures the camera always uses the same IP
  • Makes remote access consistent
  • Simplifies troubleshooting

How to Set a Static IP

  1. Log into your camera’s web interface.
  2. Go to Network Settings > TCP/IP.
  3. Change from “DHCP” to “Static IP.”
  4. Enter:
    • A unique IP within your subnet (e.g., 192.168.1.200)
    • Subnet mask (usually 255.255.255.0)
    • Default gateway (your router’s IP)
    • DNS servers (use your router’s IP or public DNS like 8.8.8.8)
  5. Save and reboot the camera.

Now, no matter what happens on the network, your camera will always respond to the same IP address.

Step 6: Test Connectivity with Ping

Before relying on the IP address, verify that your device can communicate with the camera. The ping command sends a small packet of data to test reachability.

How to Ping an IP Address

  1. Open Command Prompt (Windows) or Terminal (macOS/Linux).
  2. Type: ping [camera_IP] (e.g., ping 192.168.1.100)
  3. Press Enter.

If you receive replies like “Reply from 192.168.1.100: bytes=32 time=2ms TTL=64,” the camera is online and responsive.

If you get “Request timed out,” double-check:

  • Is the camera powered on?
  • Are cables properly connected?
  • Did you enter the correct IP?

Troubleshooting Common Issues

Problem: Can’t Find the Camera on the Network

Solution: Ensure the camera is connected to the same network as your computer. For wired cameras, check Ethernet cables. For wireless models, confirm Wi-Fi credentials are correct.

Problem: Multiple Devices Show the Same Name

Solution: Use the MAC address (found in router settings or on the camera label) to distinguish devices. Each MAC is unique to a hardware device.

Problem: Login Page Doesn’t Load

Solution: Try a different browser, clear cache, or disable ad blockers. Also, confirm the camera supports HTTP access (some only support HTTPS or ONVIF protocols).

Problem: IP Address Changes After Reboot

Solution: Assign a static IP as described earlier. Avoid reserving IPs only in the router unless your camera supports DHCP reservation.

Advanced Tips for Professionals

For IT professionals or advanced users managing dozens of cameras, consider these strategies:

  • Use ONVIF-compliant software like Milestone XProtect or iSpy to auto-discover cameras across subnets.
  • Implement VLAN segmentation to isolate camera traffic and improve security.
  • Enable SNMP monitoring to track device status and IP assignments centrally.
  • Deploy centralized NVR systems that automatically manage IP configurations.

These approaches scale well for businesses with complex surveillance needs.

Conclusion

Getting the IP address of your CCTV camera is a fundamental skill for anyone managing a surveillance system. Whether you use a simple label search, a network scanner, or your router’s admin panel, the process becomes second nature with practice. Remember to assign static IPs whenever possible and keep your firmware updated for optimal performance and security.

By following this guide, you’re not just finding an IP number—you’re unlocking full control over your security infrastructure. From viewing live feeds on your phone to configuring alerts and recordings, everything starts with that one piece of information: the IP address.

Stay safe, stay secure, and happy monitoring!
