How to Install Reolink Poe Camera Step by Step Guide

Installing a Reolink PoE camera is a straightforward, DIY-friendly process that delivers reliable, high-resolution surveillance with minimal setup. Simply connect the camera to a PoE switch or injector using an Ethernet cable, then power up and configure it via the Reolink app for seamless remote access. With plug-and-play functionality and no need for extra power cables, your security system is up and running in minutes.

Key Takeaways

• Plan camera placement: Choose strategic locations for optimal coverage and minimal blind spots.
• Use PoE switch: Connect camera directly to a PoE switch for power and data via one cable.
• Run Ethernet cable: Securely route Cat5e/Cat6 cables from switch to camera location.
• Mount securely: Use included hardware to fix camera firmly on walls or ceilings.
• Configure via Reolink app: Set up camera settings, alerts, and storage through the mobile app.
• Test night vision: Verify infrared functionality in low-light conditions post-installation.

Understanding the Reolink PoE Camera System

What is a PoE Camera?

Power over Ethernet (PoE) cameras represent a significant advancement in surveillance technology, combining power delivery and data transmission through a single Ethernet cable. Unlike traditional analog systems requiring separate power and video cables, PoE technology streamlines installation while maintaining high performance. The Reolink PoE camera system leverages this innovation, offering a plug-and-play solution that delivers both 12V DC power and Gigabit data speeds over a single Cat5e/Cat6 cable. This eliminates the need for power outlets near camera locations, making it ideal for outdoor installations where access to electricity is limited.

Reolink’s PoE cameras, such as the popular RLK8-800B4 and RLC-811A models, support IEEE 802.3af/at PoE standards, ensuring compatibility with most network switches and injectors. These cameras typically feature 4K Ultra HD resolution, advanced night vision (up to 100 feet), motion detection, and two-way audio. The integration of Power over Ethernet not only simplifies wiring but also enhances reliability—PoE cables are less susceptible to interference than coaxial cables used in analog systems. For homeowners and small businesses, this translates to a more professional-grade surveillance setup without the complexity of traditional systems.

Why Choose Reolink for Your Surveillance Needs?

Reolink stands out in the crowded security camera market due to its focus on user-friendly design, robust feature sets, and cost-effectiveness. Their PoE cameras come equipped with AI-powered person/vehicle detection, reducing false alerts from leaves or animals. The Reolink app (available for iOS and Android) provides seamless remote access, real-time alerts, and cloud storage options. Additionally, Reolink’s local storage via microSD cards or NVRs ensures privacy and eliminates monthly subscription fees for basic functionality.

Another key advantage is Reolink’s commitment to open standards. Their cameras support ONVIF and RTSP protocols, allowing integration with third-party NVRs like Synology Surveillance Station or Blue Iris. For DIY enthusiasts, this flexibility is invaluable. Whether you’re setting up a single-camera system or a multi-camera network, Reolink’s ecosystem scales effortlessly. With a 2-year warranty and responsive customer support, Reolink delivers enterprise-grade reliability at consumer-friendly prices.

Pre-Installation Planning and Requirements

Assessing Your Surveillance Needs

Before installing your Reolink PoE camera, conduct a thorough site survey to determine optimal camera placement. Start by identifying critical areas: entry points (doors, windows), high-traffic zones (driveways, hallways), and vulnerable spots (backyards, garages). Use a floor plan or sketch to map camera locations, ensuring overlapping coverage to eliminate blind spots. For outdoor installations, consider environmental factors like weather exposure, lighting conditions, and potential obstructions (trees, poles).

Example: A typical suburban home might require 4-6 cameras:

• Front door (wide-angle view of porch and street)
• Back door (focused on patio and yard)
• Driveway (long-range coverage for vehicle identification)
• Side yard (motion-triggered alerts for perimeter security)
• Interior (living room or hallway for indoor monitoring)
• Garage (detection of vehicle entry/exit)

For businesses, prioritize customer-facing areas (entrances, cash registers) and inventory storage zones. Always comply with local privacy laws—avoid pointing cameras at neighboring properties or public sidewalks without consent.

Gathering Essential Tools and Materials

Successful Reolink PoE camera installation requires the right tools and components. Here’s a checklist of essentials:

• Reolink PoE cameras: Ensure you have the correct number and model (e.g., RLC-520A for 5MP, RLC-811A for 4K).
• Network Video Recorder (NVR): For multi-camera setups, use a Reolink NVR (e.g., RLN8-410) to manage recordings and alerts.
• Ethernet cables: Cat6 cables (shielded for outdoor use) in required lengths. Pre-terminate with RJ45 connectors or use field-terminated cables.
• PoE switch/injector: A PoE+ switch (e.g., Reolink PoE Switch 1016) or midspan injector to power cameras.
• Drill and bits: Masonry bits for concrete/brick, spade bits for wood.
• Cable clips and conduits: For neat cable management and protection.
• Stud finder and ladder: For wall installations and reaching high locations.
• Smartphone/tablet: For camera setup via the Reolink app.
• Network tester: To verify cable integrity (optional but recommended).

Pro Tip: Purchase a PoE tester (e.g., Klein Tools VDV526-052) to check voltage and data transmission before finalizing installations.

Network Infrastructure Considerations

PoE cameras demand robust network infrastructure to function reliably. First, ensure your router supports Gigabit Ethernet to handle high-resolution video streams. For NVR setups, connect the NVR to your router via a dedicated Ethernet cable. If using a PoE switch, link it to the router with a separate cable to avoid bandwidth bottlenecks.

Bandwidth calculation example:
A 4K Reolink camera (RLC-811A) uses ~20 Mbps per stream. For a 4-camera system, you need:

• 4 cameras × 20 Mbps = 80 Mbps (local network)
• + 20 Mbps (remote access) = 100 Mbps total

This requires a router with at least 100 Mbps throughput. For larger systems (8+ cameras), upgrade to a 1 Gbps router and switch.

For outdoor installations, plan cable routes carefully:

• Use weatherproof conduit (PVC or metal) for exposed cables.
• Maintain 10-15 feet distance from power lines to prevent interference.
• Label cables at both ends for easy troubleshooting.

If running cables through walls, drill at a 45-degree angle to avoid structural damage.

Step-by-Step Installation Process

Mounting the Camera Hardware

Begin by mounting the camera at the desired location. Reolink cameras typically come with a three-axis bracket for flexible positioning. Follow these steps:

1. Mark drill points using the camera’s mounting template (included in the box).
2. Drill pilot holes (6mm for masonry, 4mm for wood) and insert wall anchors.
3. Secure the bracket with screws, ensuring it’s level (use a bubble level).
4. Attach the camera to the bracket and adjust the angle:
   • Front door: Tilt downward 15-20° to capture faces.
   • Driveway: Pan 45-60° from the house to cover vehicle paths.
5. Tighten the locking knob to fix the position.

For soffit installations, use a soffit mount kit (sold separately) to protect the camera from rain. Outdoor cameras should have a minimum IP66 rating for dust/water resistance.

Running and Terminating Ethernet Cables

Cable installation is the most time-consuming step. Here’s a proven method:

1. Measure the distance from the camera to the NVR/PoE switch and add 10% extra length.
2. Run the cable along the planned route, securing it with clips every 12 inches.
3. For wall penetrations:
   • Drill a 1-inch hole and insert a rubber grommet.
   • Use weatherproof sealant (e.g., silicone caulk) around the hole.
4. Terminate the cable with RJ45 connectors:
   • Strip 1 inch of jacket, untwist pairs, and arrange wires in T568B order.
   • Trim to 0.5 inches, crimp with a professional-grade tool.
   • Verify connectivity with a cable tester.

Pro Tip: For long runs (>100 feet), use Cat6a shielded cable to prevent signal degradation. Avoid sharp bends (maintain >4x cable diameter radius).

Connecting to Power and Network

With the cable in place, connect the camera to the network:

1. Plug the Ethernet cable into the camera’s PoE port (marked with a lightning bolt icon).
2. At the NVR/switch end:
   • For NVR: Insert the cable into a PoE port on the NVR (e.g., RLN8-410).
   • For switch: Connect to a PoE+ port, then link the switch to the router.
3. Power on the NVR/switch. The camera will boot in ~30 seconds (LED indicator turns solid green).

If using a PoE injector:

1. Connect the injector’s PoE port to the camera.
2. Link the LAN port to the router.
3. Plug the injector into a power outlet.

Troubleshooting: If the camera doesn’t power on, check for:

• Incorrect cable termination
• Damaged RJ45 connectors
• Insufficient PoE power (use a PoE tester)

Configuring the Camera and NVR

Initial Setup via Reolink App

Download the Reolink app (iOS/Android) and follow these steps:

1. Tap Add Device and select “PoE Camera” or “NVR.”
2. Scan the QR code on the camera/NVR or manually enter the UID.
3. Follow the prompts to:
   • Set a strong admin password (12+ characters, mix of letters/numbers).
   • Connect to your Wi-Fi network (for remote access).
   • Update firmware (critical for security patches).
4. Name each camera (e.g., “Front Door,” “Backyard”) for easy identification.

For NVRs, the app will automatically detect connected cameras. Assign each camera to a specific channel.

Adjusting Camera Settings for Optimal Performance

Fine-tune settings via the app or NVR interface:

• Video Quality: Set to “4K” or “2K” for critical areas; “720p” for low-light zones.
• Motion Detection:
  • Enable AI detection (person/vehicle) to reduce false alerts.
  • Adjust sensitivity (60-80% for outdoors).
  • Define detection zones (e.g., exclude busy streets).
• Night Vision:
  • Enable “Smart IR” to prevent overexposure of nearby objects.
  • Set IR mode to “Auto” for dynamic adjustments.
• Recording Schedule:
  • Continuous recording: 24/7 for high-security areas.
  • Motion-triggered: For low-traffic zones to save storage.
• Audio: Enable two-way talk (test microphone/speaker).

Pro Tip: Use the Snapshot feature to capture high-resolution images during alerts.

Setting Up Remote Access and Alerts

Enable cloud and push notifications:

1. In the app, go to Device Settings > Push Notification.
2. Customize alerts:
   • Select “Person” or “Vehicle” detection for critical zones.
   • Disable alerts for low-priority areas (e.g., side yard at night).
3. For cloud storage (optional):
   • Subscribe to a Reolink plan (Basic: 7-day history, Premium: 30-day).
   • Enable Cloud Backup in settings.
4. For remote access:
   • Ensure the NVR/router has port forwarding enabled (default: 9000/UDP).
   • Use DDNS (e.g., Reolink’s free service) if you don’t have a static IP.

Test remote access by viewing the camera from an external network (e.g., mobile data).

Advanced Features and Troubleshooting

Integrating with Smart Home Systems

Reolink PoE cameras work with major smart home platforms:

• Google Home: Link your Reolink account via the Google Home app for live feeds on Nest Hub.
• Amazon Alexa: Enable the Reolink skill to view cameras on Echo Show.
• Home Assistant: Use the Reolink integration for local control and automation.

Example: Create an Alexa routine to show the front door camera when the doorbell is pressed.

For advanced users, Reolink supports:

• ONVIF/RTSP: Integrate with third-party NVRs like Milestone or SecuritySpy.
• FTP Upload: Automatically save clips to a NAS or server.
• Email Alerts: Send motion-triggered snapshots to your inbox.

Pro Tip: Use RTSP streams in OBS Studio for live surveillance displays.

Common Installation Issues and Solutions

Here’s a troubleshooting guide for frequent problems:

Issue	Possible Cause	Solution
Camera not powering on	Faulty PoE injector/switch	Test with another injector or switch
Blurry video	Incorrect focus	Adjust focus ring on camera lens
False motion alerts	High sensitivity	Lower sensitivity or define detection zones
No night vision	IR LEDs disabled	Enable IR mode in camera settings
Remote access fails	Port blocking	Check router firewall and enable port forwarding
Audio distortion	Mic obstruction	Clean microphone grille with compressed air

For persistent issues, reset the camera to factory settings (press the reset button for 10 seconds) or contact Reolink support.

Maintenance and Upgrades

Regular maintenance ensures long-term reliability:

• Monthly: Clean camera lenses with a microfiber cloth.
• Quarterly: Check cable connections for corrosion (outdoor installations).
• Biannually: Update firmware and test backup storage.

For upgrades:

• Add cameras to existing NVRs (most support 8-16 channels).
• Expand storage with larger HDDs (NVRs support up to 12TB).
• Integrate with access control systems (e.g., door locks via Home Assistant).

Pro Tip: Use Reolink’s PoE Extender to extend cable runs beyond 100 meters.

Conclusion: Securing Your Property with Confidence

Installing a Reolink PoE camera system is a strategic investment in safety and convenience. By following this guide, you’ve learned to plan, mount, connect, and configure a surveillance network tailored to your needs. From the simplicity of PoE cabling to the power of AI-driven detection, Reolink delivers a solution that balances cutting-edge technology with DIY accessibility.

Remember, the key to success lies in meticulous planning and attention to detail. Assess your property’s unique requirements, invest in quality materials (like Cat6 cables and weatherproof conduits), and take advantage of Reolink’s user-friendly interface. Whether you’re a homeowner deterring package thieves or a business owner monitoring inventory, a properly installed Reolink system provides peace of mind 24/7.

As technology evolves, Reolink continues to innovate—expect features like license plate recognition, facial detection, and solar integration in future models. But even today’s systems offer remarkable value. With your new Reolink PoE cameras operational, you’re not just installing security equipment; you’re building a smarter, safer environment for your family or business. Stay vigilant, stay informed, and let Reolink be your trusted partner in surveillance excellence.

Frequently Asked Questions

How do I install a Reolink PoE camera for the first time?

To install a Reolink PoE camera, start by mounting the camera, connecting it to a PoE switch or NVR using an Ethernet cable, and powering up the system. Use the Reolink app or client to add the camera via the “+” icon and follow the on-screen setup wizard.

Can I install Reolink PoE cameras without a PoE switch?

Yes, you can use a PoE injector (sold separately) to power your Reolink PoE camera if you don’t have a PoE switch. Connect the injector between your router and the camera using Ethernet cables to deliver both power and data.

What tools do I need to install a Reolink PoE camera?

You’ll need a drill, screws, a ladder (for ceiling/wall mounting), and an Ethernet cable (Cat 5e or higher). A PoE switch, injector, or NVR is required to power the camera and enable network connectivity during installation.

How do I connect my Reolink PoE camera to Wi-Fi?

Reolink PoE cameras require a wired Ethernet connection and cannot connect to Wi-Fi directly. However, you can use a Reolink PoE-to-Wi-Fi converter or a wireless bridge to enable remote viewing via the app.

Why isn’t my Reolink PoE camera powering on after installation?

Check that the PoE switch/injector is working and the Ethernet cable is securely connected. Test with another cable or port to rule out hardware issues, and ensure the camera’s LED indicator is active.

Can I install Reolink PoE cameras outdoors?

Yes, most Reolink PoE cameras are IP66/IP67-rated for weatherproof outdoor installation. Ensure the mounting surface is stable and the Ethernet cable connections are protected from moisture using waterproof tape or conduit.
