How to Install Ring Floodlight Camera with Bonus Chime Pro

This guide walks you through installing your Ring Floodlight Camera with Bonus Chime Pro, from mounting to syncing. You’ll get clear steps, pro tips, and troubleshooting help to ensure a smooth setup.

Key Takeaways

• Turn off power first: Always shut off electricity at the breaker before wiring to avoid shocks or damage.
• Use the Chime Pro for better connectivity: The included Chime Pro extends Wi-Fi range and ensures reliable alerts.
• Mount at 9–10 feet high: This height gives the best camera angle and floodlight coverage.
• Test connections before finalizing: Power up and check the camera feed before securing all screws.
• Use the Ring app for setup: The app guides you through pairing, settings, and Chime Pro syncing.
• Keep wires neat and protected: Secure loose wires with clips and avoid sharp bends to prevent damage.
• Update firmware regularly: Keep your devices updated for security and performance improvements.

How to Install Ring Floodlight Camera with Bonus Chime Pro

Installing a Ring Floodlight Camera with Bonus Chime Pro is a smart way to boost your home security. This all-in-one device combines bright LED floodlights, a motion-activated HD camera, two-way audio, and a built-in siren. Plus, the included Chime Pro extends your Wi-Fi signal so your camera stays connected—even in areas with weak coverage.

In this guide, you’ll learn how to install your Ring Floodlight Camera step by step. We’ll cover everything from turning off power and mounting the unit to setting up the Chime Pro and customizing alerts in the Ring app. Whether you’re a DIY beginner or a seasoned pro, this guide will help you get your system up and running safely and efficiently.

By the end, you’ll have a fully functional security system that deters intruders, captures clear footage, and sends instant alerts to your phone. Let’s get started!

What You’ll Need Before You Begin

Before you touch any wires or climb a ladder, make sure you have all the tools and materials ready. This will save time and reduce frustration during installation.

Tools and Materials

• Ring Floodlight Camera (with mounting bracket)
• Bonus Chime Pro (included in the box)
• Phillips-head screwdriver
• Wire strippers
• Voltage tester (non-contact)
• Ladder (stable and tall enough)
• Electrical tape
• Wire nuts (usually included with the camera)
• Smartphone or tablet with the Ring app installed
• Wi-Fi network name and password

Check Your Existing Wiring

Your current outdoor light fixture should have three wires: black (hot), white (neutral), and green or bare copper (ground). If your setup is different—like low-voltage or no existing wires—you may need a professional electrician or a battery-powered alternative.

Also, confirm your Wi-Fi signal reaches the installation area. The Chime Pro helps, but a weak starting signal can still cause issues. Use your phone to check signal strength at the spot where you plan to mount the camera.

Step 1: Turn Off Power at the Breaker

Safety first! Working with electricity is dangerous if you skip this step. Even if the light switch is off, power may still be flowing to the wires.

How to Safely Shut Off Power

1. Go to your home’s electrical panel (breaker box).
2. Locate the circuit that controls your outdoor light. It’s often labeled “Exterior,” “Porch,” or “Floodlight.”
3. Flip the breaker to the OFF position.
4. Use a non-contact voltage tester on the wires at the fixture to confirm no electricity is present.

If the tester beeps or lights up, double-check the breaker. Never proceed until you’re 100% sure the power is off.

Step 2: Remove the Old Light Fixture

Now that the power is off, it’s time to remove your existing outdoor light.

Unscrew and Disconnect

1. Use a Phillips-head screwdriver to remove the screws holding the old fixture to the wall or junction box.
2. Gently pull the fixture away from the wall to expose the wires.
3. Unscrew the wire nuts connecting the fixture wires to the house wires.
4. Carefully disconnect the wires. Set the old fixture aside.

Keep the wire nuts—you’ll need them later. If the wires are frayed or damaged, trim them with wire strippers and expose fresh copper before reconnecting.

Step 3: Prepare the Ring Floodlight Camera

Your Ring Floodlight Camera comes with a mounting bracket and all necessary hardware. Let’s get it ready for installation.

Attach the Mounting Bracket

1. Take the metal mounting bracket from the box.
2. Hold it against the wall where you removed the old light.
3. Use a pencil to mark the screw holes.
4. Drill pilot holes if needed (especially for brick or concrete).
5. Secure the bracket with the provided screws using a screwdriver.

Make sure the bracket is level. A crooked mount will tilt the camera and reduce its effectiveness.

Connect the Wires

Now, connect the camera’s wires to your home’s wiring:

• Black wire (camera) → Black wire (house): This is the hot wire. Twist them together and secure with a wire nut.
• White wire (camera) → White wire (house): This is the neutral wire. Connect and cap with a wire nut.
• Green or bare wire (camera) → Green or bare wire (house): This is the ground wire. Connect and secure.

Wrap each connection with electrical tape for extra protection. Tuck the wires neatly into the junction box so they don’t get pinched when you attach the camera.

Step 4: Mount the Camera

With the wires connected, it’s time to attach the camera to the bracket.

Secure the Camera

1. Align the camera’s backplate with the mounting bracket.
2. Slide it into place until it clicks or sits flush.
3. Use the provided security screw to lock it in place. This prevents tampering.

Adjust the camera angle so it faces the area you want to monitor—like your driveway, front door, or backyard. The ideal height is 9 to 10 feet above the ground. This gives a wide field of view and reduces blind spots.

Test the Connection

Turn the power back on at the breaker. The camera should power up within 30 seconds. You’ll see lights on the camera and hear a chime if it’s working.

If nothing happens, turn the power off again and double-check your wire connections. Loose or incorrect wiring is the most common cause of failure.

Step 5: Set Up the Ring App

The Ring app is your control center. It lets you view live video, receive alerts, talk through the camera, and manage settings.

Download and Open the App

1. Download the Ring app from the App Store (iOS) or Google Play (Android).
2. Open the app and create a Ring account if you don’t have one.
3. Tap “Set Up a Device” and select “Security Cameras.”
4. Choose “Floodlight Cam” from the list.

Scan the QR Code

Every Ring camera has a QR code on the back or inside the battery compartment. Use your phone’s camera to scan it. This links the device to your account.

If the scan fails, you can enter the serial number manually. It’s usually found near the QR code.

Connect to Wi-Fi

The app will prompt you to connect the camera to your Wi-Fi network. Select your home network and enter the password.

Tip: Use a 2.4 GHz network. Ring cameras don’t support 5 GHz. If your router broadcasts both, make sure you’re connecting to the 2.4 GHz band.

Step 6: Install and Sync the Chime Pro

The Bonus Chime Pro is a game-changer. It plugs into any standard outlet and extends your Wi-Fi signal to the camera. It also plays custom alert sounds when motion is detected.

Plug in the Chime Pro

1. Find an indoor outlet near the camera’s location—ideally within 100 feet.
2. Plug in the Chime Pro. It will power on and show a solid blue light.
3. Open the Ring app and go to “Devices.”
4. Tap “Add Device” and select “Chime Pro.”
5. Follow the on-screen instructions to sync it with your account.

Test the Connection

Once synced, the app will show the Chime Pro as online. It will also display the signal strength between the Chime Pro and your camera.

If the signal is weak, try moving the Chime Pro to a different outlet. Avoid placing it behind thick walls, metal objects, or appliances like microwaves.

Customize Alert Sounds

In the app, you can choose from several chime sounds or upload your own. You can also adjust the volume or turn off the sound if you prefer silent alerts.

This feature is great for families—kids can hear when someone’s at the door, and you’ll know if motion is detected even if your phone is on silent.

Step 7: Adjust Camera Settings

Now that everything is connected, it’s time to fine-tune your camera for the best performance.

Motion Zones

In the Ring app, go to your camera’s settings and select “Motion Settings.” You can draw custom zones to monitor specific areas—like your front walkway—and ignore others, like a busy street.

This reduces false alerts from passing cars or animals.

Motion Sensitivity

Adjust the sensitivity slider based on your environment. High sensitivity catches small movements but may trigger false alarms. Low sensitivity reduces alerts but might miss subtle activity.

Start with medium sensitivity and adjust after a few days of testing.

Light Settings

You can set the floodlights to turn on automatically when motion is detected. Choose the brightness level and how long they stay on (15 seconds to 10 minutes).

You can also schedule the lights to turn on at sunset and off at sunrise for added security.

Two-Way Audio

Test the microphone and speaker by tapping the talk button in the app. Speak and listen to ensure clear communication.

This feature lets you greet visitors, scare off intruders, or talk to delivery drivers.

Step 8: Final Checks and Tips

Before you call the job done, run through these final checks to ensure everything works perfectly.

Test All Features

• Walk in front of the camera to trigger motion alerts.
• Check that you receive a notification on your phone.
• Open the live view and confirm the video is clear.
• Test the two-way audio.
• Verify the floodlights turn on with motion.
• Listen for the Chime Pro alert sound.

Secure Loose Wires

Use wire clips or zip ties to secure any loose wires to the wall or junction box. This prevents them from getting damaged by weather or animals.

Update Firmware

The Ring app will notify you if a firmware update is available. Always install updates to improve security and add new features.

Label Your Breaker

If your breaker isn’t labeled, now’s the time to fix that. Write “Floodlight Camera” on a sticker and place it on the breaker. This makes future maintenance easier.

Troubleshooting Common Issues

Even with careful installation, problems can happen. Here’s how to fix the most common issues.

Camera Won’t Power On

• Double-check that the breaker is on.
• Use a voltage tester to confirm power at the wires.
• Recheck wire connections—loose or reversed wires can prevent power.
• Ensure the ground wire is properly connected.

Poor Wi-Fi Signal

• Move the Chime Pro closer to the camera.
• Avoid placing the Chime Pro near metal objects or thick walls.
• Restart your router and the Chime Pro.
• Consider a Wi-Fi extender if the signal remains weak.

False Motion Alerts

• Adjust motion zones to exclude busy areas.
• Lower motion sensitivity.
• Trim tree branches or shrubs that sway in the wind.
• Ensure the camera isn’t pointed at reflective surfaces like windows.

Chime Pro Not Syncing

• Make sure it’s plugged into a working outlet.
• Restart the Chime Pro by unplugging it for 10 seconds.
• Reopen the Ring app and try syncing again.
• Check that your phone is connected to the same Wi-Fi network.

Floodlights Not Turning On

• Check the light settings in the app.
• Ensure motion is being detected (test by walking in front).
• Verify the bulbs are properly seated (if replaceable).
• Confirm the camera is receiving enough power.

Maintenance and Long-Term Care

To keep your Ring Floodlight Camera working smoothly, follow these maintenance tips.

Clean the Lens Monthly

Use a soft, dry cloth to wipe the camera lens. Avoid harsh chemicals or abrasive materials that can scratch the surface.

Check for Obstructions

Trim plants, clean gutters, and remove debris that might block the camera’s view or trigger false alerts.

Inspect Wiring Annually

Turn off power and check wire connections for corrosion, fraying, or looseness. Re-tighten or replace as needed.

Update the App and Firmware

Enable automatic updates in the Ring app settings. This ensures you always have the latest features and security patches.

Review Footage Regularly

Check your event history in the app. Look for patterns—like frequent alerts at certain times—and adjust settings accordingly.

Conclusion

Installing a Ring Floodlight Camera with Bonus Chime Pro is a smart investment in your home’s security. With bright lights, HD video, two-way talk, and reliable Wi-Fi coverage, you’ll have peace of mind day and night.

By following this guide, you’ve safely mounted the camera, connected it to power and Wi-Fi, synced the Chime Pro, and customized your settings. You’re now ready to enjoy real-time alerts, crystal-clear footage, and enhanced protection for your property.

Remember to test all features, keep your system updated, and perform regular maintenance. If you run into issues, the troubleshooting tips above will help you resolve them quickly.

Stay safe, stay connected, and enjoy the confidence that comes with a well-installed Ring security system.
